Illustration of Triple Modular redundancy - 3 identical logic elements compute outputs from inputs. The output are compared in a separate element which outputs the value that match in 2 or 3 on its inputs and flags the erroneous logic element if any.
Source: https://www.rs-online.com/designspark/when-redundancy-is-a-good-thing
